Schneideinsätze mit Teilprofil für die Innenbearbeitung von Whitworth-Gewinden, Mindestbohrungsdurchmesser 8 mm. CHAMGROOVE - Teil des CHAMELEON-Multifunktion-System
Anwendung |
Threading (Int.) |
Beschichtung |
TiCN+TiN |
Sorte |
IC528 |
Eckenradius [mm] |
0.05 mm |
Zu bearbeitender Werkstoff |
Stainless Steel |
Steel |
Super-Alloys / Titanium |
Schneidwerkstoff |
Carbide |
Werkzeugtyp |
Groove-Turn Precision Inserts |
Profilwinkel [°] |
55 |
Schneidkantenlänge [mm] |
7.78 mm |
Gewindestandard [mm] |
THFT |
Barcode:
|
2023911000004 |
Anwendung |
Threading (Int.) |
Beschichtung |
TiCN+TiN |
Sorte |
IC528 |
Eckenradius [mm] |
0.05 mm |
Zu bearbeitender Werkstoff |
Stainless Steel |
Steel |
Super-Alloys / Titanium |
Schneidwerkstoff |
Carbide |
Werkzeugtyp |
Groove-Turn Precision Inserts |
Profilwinkel [°] |
55 |
Schneidkantenlänge [mm] |
7.78 mm |
Gewindestandard [mm] |
THFT |
Barcode:
|
2023911000004 |
